C40 Inrunner Brushless Motors

The most popular for 1/12 cars

Motor Diameter:	35.8mm
Motor Length:	50mm
Shaft Diameter:	3.17mm
Shaft Length:	15mm
Weight:	160g
Mounting Hole Size:	M3, pitch 25mm
Mounting Hole Depth:	4mm Max.

Order Name	RPM/V	No-load Current （7.4V）	Max. Amps	Resistance	Max. RPM
C40/9T	4300	2.4A	45A	0.0119	58000
C40/10T	3900	2.2A	40A	0.0148	58000
C40/11T	3600	1.9A	38A	0.0179	58000
C40/12T	3300	1.6A	35A	0.0213	58000
C40/13T	3000	1.4A	32A	0.0248	58000
